    Inverter Controlled Mercerizing Machine Mistubishi Inverter Chainless / Clip / Combined Type

    Ask Lasest Price
    Brand Name : VIROCK
    Model Number : VK
    Certification : ISO9001
    Price : NEGOTIABLE
    Payment Terms : L/C, T/T, D/A
    Supply Ability : 4 sets per month
    Delivery Time : 60-90 days
    • Product Details
    • Company Profile

    Inverter Controlled Mercerizing Machine Mistubishi Inverter Chainless / Clip / Combined Type

    Roller & clip mercerizing machine , high efficiency , inverter controlled


    APPLICATION:


    It is applied to all of the cellulose fibers & their blenders or interwoven fabrics including yarn dyed, towel

    home textile and denim fabrics.


    Process:

    fabric feed frame →18 pairs thick alkali chainless mercerizing box→2 bowl high-efficiency squeeze→12.5 pairs Weak alkali stabilize mercerizing box→2 bowl high-efficiency squeeze→【steam washing box(5/6) →2-bowl padder】X8→steam washing box(5/6)→2 bowl high-efficiency squeezer→2x10 drying cylinder (dia.:800mm)→Fabric outlet


    Main SPECIFICATIONS:


    1. type:chainless/clip/combined

    2. working width:1800-3200m

    3. Machine speed:10-70m/min process speed: 10-60m/min

    4. Transmission mode: frequency conversion driving, Inovance

    5. Controlling device: Mitsubishi PLC

    6. Supplying steam pressure: ≥0.4Mpa.

    7. Compressed air pressure: ≥0.5Mpa.

    8. Supplying water pressure: ≥0.2MPa.

    9. Power supply:380V 50HZ,220V 50HZ:

    10. Fabric specification: 60GSM—300GSM


    About the chainless mercerizing box


    Thick alkali chainless mercerizing box has 18 upper and 18 bottom straight rollers. 2 bottom rollers are driven, respectively driven by 4KW motor. Weak alkali stabilize mercerizing box has 13 upper and 12 bottom straight rollers. 1 bottom rollers are loaded, driven by 4kw motor.Upper rollers are all rubber rollers, dia.299mm seamless steel pipe covered with 12mm 73A±2.5 acrylonitrile rubber. Bottom rollers are all the dia.295mm seamless stainless steel pipe with the screw surface. The diameter of the upper roller is 315mm; the bottom is 299mm. The rollers are dealt with static balance, runs smoothly. The body of the tank is made of beam steel, the bottom has dia.320mm clean hole and auto-filter tank. Totally there are 2 auto-filters and tanks.


    Quality Inverter Controlled Mercerizing Machine Mistubishi Inverter Chainless / Clip / Combined Type for sale
