    Open Screen Head Cloth Printing Machine , Rotary Printing Machine Textile

    Friendly HMI operation Rotary Screen Printing Machine , Open screen head


    1. Description and application:
    The rotary screen printing machine is a popular type printing machine. It is innovation of technology and reseach of the market. It suits to print the natural fiber, chemical fiber and other blended woven and knitting fabric.

    2. Main features:
    1) Open-type screen head. The screen is easy to be installed and dismantled.
    2) Good rigidity magnetic table. The pressure of magnet rod is unlimited adjustable, which suitable for different weight fabrics.
    3) Servo motor driving individually,register accurately and reliably.
    4) Auto inspect and display malfunction, guide and check to deal with the malfunction quickly.
    5) The friendly HMI operation system.
    6) Screen frame can be lift up on the single side, which is convenient to clean and maintain.
    7) High quality mechnical parts and electrical elements which purchased from the global market.
    8) Residual paste returned device.
    3. Specifications:
    Fabric weight: 50g/㎡~600g/㎡
    Printing width: 1200mm- 3200mm
    Printing color: Max. 16 sets
    Printing repeat: 640mm/820mm/914mm/1018mm/1168mm
    Machine speed:4~80M/min
    Type of screen head driving: Individual driving
    Register precision: ±0.1mm
    Register adjustment rangeVertical: no limited
    Horizontal: ±10mm
    Diagonal: ±5mm
    Drying mode: 3-layer fabric passing
    Chambers of dryer: Optional
    Heating source: Steam/thermal oil/ gas
    Fabric-entry and exit mode: Open-width
    .
