    Single Pin Stenter Machine Textile Finishing Machine , Fabric Stenter Machine

    Ask Lasest Price
    Brand Name : VIROCK
    Model Number : VK-280x8
    Certification : ISO9001
    Price : NEGOTIABLE
    Payment Terms : L/C, T/T, D/A
    Supply Ability : 4 sets per month
    Delivery Time : 60-90 days
    • Product Details
    • Company Profile

    Single Pin Stenter Machine Textile Finishing Machine , Fabric Stenter Machine

    Open-width Mosquito-net finishing Stenter , Single pin , Thermal oil heated


    1. Description:

    This type of Virock stenter is designed to produce Mosquito-net. Together with the pad-mangle, the stenter can apply different special chemicals on the mosquito netting, strech and heat set the net at some temperature.

    2. Machine features:

    1) With HMI, PLC, inverters, the machine Automatic grade is high.

    2) The exhaust pipe is placed inside of the chamber, which prevent the condensed water from the fabric.

    3) High quality mosquito-net can be finished due to tension-free processing.

    4) The width of each chamber can be adjusted individually.

    5) The temperature of each chamber can be set on the HMI easily.


    3. Technical data:


    Normal width:1400-3600mmWorking width:1200-3600mm
    Heat source system:nature gas /oil / steam / electricity/combinedWidth adjustment range:500-3600mm
    No. of Chambers2-15Max. Temperature of chamber:230℃
    Fabric held by:clip/pin/combinedAir pressure:above 0.5mpa
    Overfeed range:-10% to 80%Installation power:App. 120Kw
